Consider a vector W in 2-dimensional space, as illustrated in Figure 1. It can be generated by adding together multiples of two "basis" vectors, u and v. Indeed, any vector in this space can be so generated. So what's so special about the two vectors u and v? They're perpendicular to each other ... or orthogonal. They each have a length equal to 1 ... they're normalized. Indeed, they're said to be orthonormal.

Figure 1

uv

uv= ||u|| ||v|| cos θ   where ||u|| and ||v|| denote the lengths of vectors u and v and θ is the angle between them.

uu

uu

uv

Note that uv = vu

Writing W = a u + b v we consider:
Wu = a uu + b vu = a (1) + b (0) = a   and   Wv = a uv + b vv = a (0) + b (1) = b.
In other words, using the "scalar" product (sometimes called the "inner product") we can extract the coefficients a and b if we're given W.

>And what if that W had more components? I mean, what if ...?
If we had an n-dimensional space with orthonormal basis vectors u₁, u₂, ... u_n, then we could write an arbitrary vector as:
W = a₁ u₁ + a₂ u₂ + ... + a_n u_n   and we could extract each coefficient using the "inner product" like so:
a₁ = Wu₁   and   a₂ = Wu₂   etc. etc.

We can then write, for any vector in our n-dimensional space:

[1]     W = (Wu1) u1 + (Wu2) u2 + ... + (Wun) un = Σ(Wuj) uj The n numbers (Wuj)   (with j going from 1 to n)   are the coefficients in the expansion of W in terms of the orthonormal basis. >And that's interesting ... to you? NOW comes the interesting part: The guy we're calling W could be a function of time, W(t). If we're careful we can choose an "orthonormal basis" which will be a collection of functions and we can express W(t) as a sum of these basis functions uj(t). W(t) = a1 u1(t) + a2 u2(t) + a3 u3(t) + ...... Well-known examples include the Fourier Series expansion of a function. The function W shown in Figure 2 is a sum: W(t) = u1(t) - (0.5)u2(t) - (0.1)u3(t) ... where u1(t) = sin(t), u2(t) = sin(2t) and u3(t) = sin(3t). The collection of functions sin(t), sin(2t), sin(3t) etc. etc. can be used as a basis to generate (almost) any function defined on 0 ≤ t ≤ 2π. Note that W must have an average value of 0 since all the sine-functions do. Indeed, if W(t) is a periodic function (like a note played on a violin) then the components u1, u2, u3 etc. are the harmonics (or overtones) associated with that note and ... >Yeah, I remember listening to the Beatles and ... Pay attention! A more "complete" basis would be: 1, cos(t), sint(t), cos(2t), sin(2t), cos(3t), sin(3t), etc. For example, if W(0) weren't 0 and/or W(-t) weren't the negative of W(t) then using only sine functions wouldn't work. Figure 2 Indeed, sin(0) = 0 and sin(-t) = - sin(t) and, of course, all sine and cosine functions have an average value of 0 over an interval such as (-π, π) or (0, 2π) ... which explains the need to include that first constant function: 1 (in case W has an average different than 0). For example, here W(t) = 1 + sin(t) - (0.5)cos(2t) - (0.1)sin(3t). Our objective is to show that, for our Stock Prices, we can use Haar Wavelets as our basis functions. Alfréd Haar (1885 - 1933), a Hungarian mathematician, mentioned these guys in an appendix to his doctoral thesis. >You said you needed some dot product, or scalar or inner producat ... or whatever you call it. Oh, yes, I almost forget. For our sines and cosines we'd use: [2]     uv= ∫ uj(t) vk(t) dt   where uj(t) and vk(t) are sin(jt) or cos(jt) or sin(kt) or cos(kt) and the integration is over, say 0 ≤ t ≤ 2π In fact, ∫ sin(jt) sin(kt) dt = ∫ sin(jt) cos(kt) dt = ∫ cos(jt) cos(kt) dt = 0   if j ≠ k. >So they're orthonormal? Uh ... not exactly. They're orthogonal, to be sure, but the scalar product of a basis with itself isn't "1", because ∫ sin2(jt) dt = ∫ cos2(jt) dt = π. >So divide each by π1/2 and they'd be orthonormal, right? Yes, but it's messy having that π1/2 hanging around. We'll stick it in when we need it. >But what about that very first basis function ... the "1"? Aah, yes. If we let u0(t) = 1, then ∫ u0(t) uk(t) dt = 0 if k ≠ 0 since ∫sin(kt) dt = ∫cos(kt) dt = 0   and   ∫ u02(t)dt = 2π. Anyway, we can now write for (almost) any function f(t): f(t) = a0 + a1cos(t) + b1sin(t) + a2cos(2t) + b2sin(2t) + a3cos(3t) + b3sin(3t) + ... To find the constants a0, a1, b1, etc. we use [1] (with an infinite number of basis functions) and the scalar product defined by [2]. Now, with Haar Wavelets ... >How about an example ... a Fourier series with some sexy f(t)? Okay, let's try f(t) a square wave, like so: Our f(t) is an "odd" function (meaning that f(-t) = - f(t)) so we only need the sine functions in our basis. We write f(t) = Σbk sin(kt). Multiply each side by sin(mt) (for an arbitrary integer m) and integrate from t = 0 to t = 2π. Then ∫f(t) sin(mt) dt = Σbk sin(mt) sin(kt) dt. That's equivalent to taking the scalar product, eh? All the terms on the right side integrate to 0 except the one where k = m. That integration (of the right side) gives Σbk sin2(mt) dt = π bm. For the left side, we split the integral into two parts:   ∫1sin(mt) f(t) dt + ∫2 sin(mt) f(t) dt The first integration is from t = 0 to t = π (where f(t) = 1) and the second is from t = π to t = 2π (where f(t) = -1). That gives: ∫1 sin(mt) dt - ∫2 sin(mt) dt = (-1/m) [cos(mπ) - cos(0)] - (-1/m) [cos(2mπ) - cos(mπ)] = (1/m) ( 2 - 2cos(mπ) ) = 0 unless m is an odd integer (which makes cos(mπ) = -1). When m is an odd integer, we get: 4/m. Finally, then, we have 4/m = π bm when m =1, 3, 5, etc., otherwise we get bm = 0 (for m an even integer). That makes bm = 4/(mπ) for m = 1, 3, 5 etc. and our square wave is then represented as the Fourier Series: f(t) = 4/(π)[ sin(t) + (1/3) sin(3t) + (1/5) sin(5t) + (1/7) sin(7t) + ... ] If we take just ten terms of the Fourier Series, namely 4/π[ sin(t) + (1/3) sin(3t) + (1/5) sin(5t) + (1/7) sin(7t) + ... + sin(19t)] ... we'd get Figure 3. >The Fourier Series is periodic, but what if f(t) isn't? Aah, if you use a series with these sines and/or cosines, you're going to get a periodic representation. Of course, with Haar Wavelets ... >Maybe it's time to switch to Haar, eh? Good idea! Figure 3 to continue P.S. There's a spreadsheet to play with which lets you gaze in awe at the sum of terms in a Fourier Series (up to 10 terms). It looks like this (Click on the picture to download):
